Pride Go Go Universal Battery Charger
In stock
$119.00
GoGo Scooter Battery Charger. Works on all GoGo models including Go Go Ultra X and Go Go Elite, GoGo Sport models
Offboard Charger - 2 Amp
Details and Specifications for the Pride Go Go Universal Battery Charger
Input Voltage = 100 - 240Vac +/-10%
Input Frequency = 50 - 60Hz
Over Voltage Protection = DC 31V Max.
Over Current Protection = DC 2.5A Max.
Leakage Current = 0.75mA Max.
Input Power = 3.5 W
Output Voltage
Fast Charge (AGM) = DC 28.8V (+/- 0.2V)
Float Charge (AGM) = DC 27.0V (+/-0.2V)
Charging Current
Fast Charge = DC 2000mA +/- 5%
Float Charge = DC 500mA
Input Standby Power = <1.0 W
Efficiency = >85% @ Full Load
Battery Charging Capacity = 7 - 22 Amp Hours
Output Cord = 2m long, SJT type (Hard Usage) with XLR 3-pin Male Connector
Operation Temperature = -13 F/-25 C to + 122 F/50 C
Manual and Videos for the Pride Go Go Universal Battery Charger
Brochure: Brochure Link
Warranty for the Pride Go Go Universal Battery Charger
GoGo Scooter Battery Charger. Works on all GoGo models including Go Go Ultra X and Go Go Elite, GoGo Sport models
Offboard Charger - 2 Amp
Details and Specifications for the Pride Go Go Universal Battery Charger
Input Voltage = 100 - 240Vac +/-10%
Input Frequency = 50 - 60Hz
Over Voltage Protection = DC 31V Max.
Over Current Protection = DC 2.5A Max.
Leakage Current = 0.75mA Max.
Input Power = 3.5 W
Output Voltage
Fast Charge (AGM) = DC 28.8V (+/- 0.2V)
Float Charge (AGM) = DC 27.0V (+/-0.2V)
Charging Current
Fast Charge = DC 2000mA +/- 5%
Float Charge = DC 500mA
Input Standby Power = <1.0 W
Efficiency = >85% @ Full Load
Battery Charging Capacity = 7 - 22 Amp Hours
Output Cord = 2m long, SJT type (Hard Usage) with XLR 3-pin Male Connector
Operation Temperature = -13 F/-25 C to + 122 F/50 C
Manual and Videos for the Pride Go Go Universal Battery Charger
Brochure: Brochure Link
